Description
This JavaCard 2.2.2 implementation by NXP is the new dual-interface (contact/contactless) edition of JCOP.
This product is targeted at the convergence of e-government, banking, and transport applications, reducing cost of development.
The support for a contactless interface makes this JCOP a highly convenient and integrative software. The product is available on 80kB EEPROM chips, dual-interface with Mifare 1k emulation.
JavaCard 2.2.2 (JCOP v2.4.1 R2, GlobalPlatform 2.1.1) 80 KByte EEPROM, DI, Mifare 1k emulation
- Technical Specifications
Product SPECIFICATIONS & FEATURES
Java Card version 2.2.2 Classic
GlobalPlatform 2.1.1
GP Secure Channel Protocol SCP01 / 02
Delegated management –
Secure box –
AVAILABLE MEMORY SIZE AND TECHNOLOGY
EEPROM (KByte) 80
CMOS technology CMOS14
MIFARE option: MIFARE 1K
eGovernment and banking performance
BAC (20 kByte read) ask for an NDA (Info@MoTechno.com)
EAC (36 kByte read) ask for an NDA (Info@MoTechno.com)
MasterCard PayPass M/Chip4 (performance comparison) ask for an NDA (Info@MoTechno.com)
CRYPTOGRAPHY
DES/TDES [bit] 56/112/168
AES [bit] 256
RSA [bit] 2048
ECC GF(p) [bit] 320
Point Addition (PACE) Yes
SHA SHA-1/2
Certifications and approvals
EMVCo hardware approval Yes
EMVCo platform approval –
VISA approvals Yes
MasterCard PIC (TAS & CAST) Yes
Common Criteria (VAN5) EAL 5+
