J3R452 JCOP 4.5

J3R452 JCOP 4.5 P71 450 KB (JavaCard 3.0.5 Classic) Dual Interface

The J3R452 JCOP4.5 powered smart card combines the robust security of GlobalPlatform 2.3 with the versatile capabilities of JavaCard 3.0.5 Classic. This synergy ensures a state-of-the-art solution, capable of securely executing Java-based applications across various domains, from financial transactions to secure access controls. With advanced features and compatibility, it stands as a reliable choice for a broad spectrum of secure applications.

* Export control — The item(s) may be subject to export control regulations. Further export outside your country may be prohibited or restricted: please contact your export control authorities.

* Die Waren können bei Ausfuhr aus der EU Ausfuhreinschränkungen nach der VERORDNUNG (EG) Nr. 1334/2000 DES RATES, des Außenwirtschaftsgesetzes (AWG), der Außenwirtschaftsverordnung (AWV) und anderen Ausfuhrbestimmungen unterliegen. Auch ohne Kennzeichnung kann sich eine Genehmigungspflicht, unter anderem durch den Endverbleib und Verwendungszweck der Güter ergeben.

*
*
SKU: NXP.J3R452.DI Category: Tags: , , , , , , , , ,

Description

J3R452 JCOP 4.5 P71D600

  • Specifications and Features

– Java Card Version 3.0.5 Classic Edition (API, Runtime Environment and Virtual Machine).
– GlobalPlatform Version 2.3.
– Secure Channel Protocol (SCP): SCP01, SCP02 or SCP03.
– Delegated Management.
– Secure Box.
– Physical Unclonable Function (PUF)
– Form factor: ISO/IEC 7810 ID-1
– T=0 or T=1 (ISO/IEC 7816)
– ISO/IEC 14443 Type A, Type B
– Dual-Interface enabled for Applets
– NVM ~ 450 KB
– Up to 688,172 bit/s over the contact interface
– Up to 848Kbps over the contactless interface

  • Available Memory and Technology

– FLASH (available before loading MIFARE, Applets, OS Addons): ~ 450KB.
– CMOS Technology CMOS040.

  • MIFARE IC

– MIFARE Plus Implementation EV2 (optional).
– MIFARE DESFire Implementation EV3 (optional).

  • Cryptographic Algorithms and Key Sizes

– DES/TDES 56b, 112b and 168b.
– AES 128/192/256b.
– RSA up to 4096b.
– Process the RSA algorithm enable on-board key generation of RSA keys with a key length of up to 4096 bits and a granularity of 8 bits or less.
– ECC GF(p) 521b.
– OnCard generation and import of OffCard-generated ECDH or ECDSA keys with a key length of up to 521 bits (ECC keys).
– SHA1 160b.
– SHA2 128b, 224b, 256b, 384b and 512b.
– Product supports Brainpool curve parameters with key lengths up to 512 bits for ECDSA/ECDH (ECC keys).
– The NXP J3R452 JCOP 4.5 supports as well EdDSA Harold Edwards Ed25519.

  • Certifications and Approvals

– EMVCo.
– Common Criteria for OS: EAL 6+ (2019).
– Federal Information Processing Standard (FIPS) 140-3.

  • Target Applications

– Electronic ID Cards.
– Electronic Passports.
– Electronic Health / Social-Benefit Cards.
– Electronic Driver’s Licenses.
– Electronic Vehicle Registration Card..
– Electronic Residence Permit.
– Consular Card.
– Electronic Voting Card.
– Tax Declaration Card.
– Public Key Infrastructure (Authentication, Digital Signature, Encryption).
– Cross-Market Applications:

    – Payment / Micropayment.
    – Cold Wallet application.
    – Public Transport.
    – Logical and Physical Access.
