Description
Dimensions: 57mm [ L ] – 7.7mm [ H ] – 12.56mm [ W ]
Weight: 5 g
IC: RTS 5169
Power supply: DC + 5V Built-in 3.3v regulator for single 5v operation
Operating temperature: 0° – 70° C
Operating humidity: 20 – 95 %
Host Interface: Serial (RS232/TTL) & USB 2.0 CCID (also compliant with USB 1.1)
Transmission speed: 12 Mbps (USB 2.0 full speed) 115,200 kbps (serial)
Standards: ISO 7816 & EMV 2000 ver.4.1 Level 1
Protocols: T = 0, T = 1 2-wire SLE 4432/42 (S=10)3-wire SLE 4418/28 (S=9) I2C (S=8)
Smart Card Interface speed: 420 Kbps (when supported by card)
Smart Card clock frequency: Up to 8 MHz
Supported Card types: 5V, 3V and 1.8V Smart Cards ISO7816 Class A, AB and C
Card size: ID-1 (full-size)
Card Thickness: 0.76 mm ± 0.08 mm
Power to Smart Card: 60mA
Power consumption: Power on 100mA max, Short circuit protection
Smart card contact resistance: 0.5 Ohm max between two line
Ripple: 100 mVp-p max
Smart card detection: Movement Detection with auto power-off Automatic Detection of Smart Card type Short Circuit and thermal protection
8 Pin Handling: C4 / C8 supported
Supported APIs: PC/SC driver (ready for 2.01)CT-API (on top of PC/SC)Synchronous-API (on top of PC/SC)OCF (on top of PC/SC) I2C (on top of PC/SC)
PC/SC Driver Support: XP SP3 32/64 Bit 2003 Server Windows® CE 5.0 / CE NET (depending on hardware) Windows® Vista (32 /64 bit), Windows® 8 Mac® OS X (Power PC / Intel) Linux®
Drivers: CCID-compliant ( Mac® OS X, Windows®, Linux® )
Status indicator: 1 led indicator (WHITE)
Compliance / Certification: Certification Microsoft® WHQL EMV 2000 Level 1 ISO 7816 USB 2.0 (USB 1.1 compatible) CCID
Safety / Environmental: FCC, CE, ROHS
Color: Black and White matte
Composition: PC
Life cycle durability: 100.000 + insertions
Warranty: Two year manufacturer’s warranty
