CardOS V4.3B

CardOS V4.3 B 32k

39,95 € [excl. Shipping Fees excl. 19% VAT.]

CardOS V4.3 B 32k is a multifunctional smart card operating system that meets the most stringent data security requirements. It offers active and passive protection for stored data, certificates and cryptographic keys.

* Export control — The item(s) may be subject to export control regulations. Further export outside your country may be prohibited or restricted: please contact your export control authorities.

* Die Waren können bei Ausfuhr aus der EU Ausfuhreinschränkungen nach der VERORDNUNG (EG) Nr. 1334/2000 DES RATES, des Außenwirtschaftsgesetzes (AWG), der Außenwirtschaftsverordnung (AWV) und anderen Ausfuhrbestimmungen unterliegen. Auch ohne Kennzeichnung kann sich eine Genehmigungspflicht, unter anderem durch den Endverbleib und Verwendungszweck der Güter ergeben.

*
*
SKU: N/A Categories: , Tags: , ,
SIM or full sized card. DISCONTINUED module :: Hurry up :: ONLY few thousand left for your order. SPECIAL PROJECT PRICING AVAILABLE; especially together with CardOS API.
QuantityPrice/unit
1 unit and more39.95 €
47.95 $
34.95 £
10 units and more34.95 €
41.95 $
30.95 £
100 units and more31.95 €
37.95 $
27.95 £
1000 units and more24.95 €
29.95 $
21.95 £

Description

  • Product Information
    CardOS V4.3 B 32k complies with ISO 7816 (parts 3, 4, 5, 8, and 9). A signature application based on CardOS V4.3 will obtain certification in accordance with the international security standard Common Criteria EAL 4+. Software packages that can be loaded later allow the operating system to be extended or adapted for special applications.In addition to the CardOS operating system, special CardOS tools such as the CardOS V4/M4 ADK (Application Development Kit) and CardOS V4.3 PDK (Package Development Kit) are offered for simple design-in and efficient testing of CardOS in projects and solutions. CardOS Api is offered for integrating the card with a PKI (public key infrastructure).
  • Standard Features
    General Features
    Runs on the hardware platforms (chip)
    SLE66CX322P (32-Kbyte EEPROM) and
    SLE66CX642P (64-Kbyte EEPROM) from Infineon.
    The SLE66CX security controller familyhas been certified according to the Common Criteria EAL 5+ security standard.
    Protection against all known security attacks
    ISO 7816-compatible commands for the applications
    Proprietary commands for the patented personalization method
    Supports PC/SC / PKCS#11 / CSP and CT-API
    Improved support of smart card readers that are not fully ISO-compliant
    Clearly structured security architecture with key management
    Up to four logical channels
    Customer- and application-centric configuration of card services and commands
    The operating system can be extended by software packages that can be subsequently loaded, for example to support additional cryptographic algorithms such as the ECC (elliptic curve cryptography) algorithm
    All packages can be executed on both Infineon platforms
    New licensing concept for CardOS packages permits subsequent enabling of further functions (investment protection)

Additional information

Weight N/A
Dimensions N/A
Form Factor

,

Body Material

Brand

OS/Branding

Software
